Machine Model
Table size |
Based on customer’s requests |
|---|---|
Transmission |
X/Y Axis Hiwin Rack and Guide Rails, Z Axis Ball Screw |
| Spindle Type | ATC HSD spindle made in Italy |
| Spindle Speed | 24000RPM/min |
| Travelling Speed | 0-70M/min |
Max working speed |
0-25M/min |
Driving servo system |
Syntec/Yaskawa servomotors |
Voltage |
AC 380/3PH/50Hz (220V optional) |
Controller |
Syntec (Osai optional) |
Tools Magazine |
6pcs 8pcs 12pcs 16pcs Linear tools(Carousel tools optional) |
Applied Materials
