Machine Specifications
| Dimensions of sliding table | 3200/435mm |
|---|---|
| Cutting length | 3200mm |
| Cutting width | 1250mm |
| Main Saw blade diameter | 400mm |
| Cutting height | 120mm |
| Speed of main saw spindle | 3000/4000/5000 rpm |
| Spindle diameter | 30mm |
| Tilting saw blade | 0-45° |
| Main motor | 7.5kw / 10Hp |
| Scoring saw blade | 120mm |
| Non-load speed | 8000rpm |
| Scoring spindle diameter | 20mm |
| Scoring motor power | 1.1kw/1.5 Hp |
| Scoring unit blade diameter | 120mm |
| Weight | 850-950kg |
| Overall dimensions | 3250x3150x900mm |
