Smart Series

A steel welded structure, vibrating treatment of aging for removal of internal stress, with good rigidity and stability
Torsion shaft forced synchronization of mechanical limit stopper balance, with high precision
The integrated hydraulic transmission system, large range of speed regulation to transmission of the sliding block, stable and reliable performance
The rear stopper and the sliding block have electrical adjustments for their stroke, with manual fine-tuning, and digital indication
The adjustment mechanism of the sliding block independent from the oil cylinder assembly to enhance the sealing effect upper mold is fitted with a tilting wrap offset mechanism
The safe guide is optional
Controller-SIKO (DRO), NC HT072, DA-41 – available as optional

HYDRAULIC PRESS BRAKE	PB-110	PB-125	PB-160	PB-200	PB-250
Nomina Pressure	1100kn	1250kn	1600kn	2000kn	2500kn
Length Of working Table	3200mm	3200mm	3200mm	3200mm	3200mm
Backgauge Range	2555mm	2555mm	2555mm	2550mm	2430mm
Depth of throat	320mm	320mm	320mm	320mm	400mm
Stroke Ram	130mm	130mm	150mm	200mm	250mm
Approaching speed	80mm/s	80mm/s	80mm/s	70mm/s	70mm/s
Working Speed	10mm/s	8mm/s	9.5mm/s	7.5mm/s	7.5mm/s
Returning speed	60mm/s	60mm/s	60mm/s	60mm/s	66mm/s
Adjustment of Ram travel	85mm	85mm	110mm	110mm	120mm
Day Light	380mm	380mm	400mm	435mm	460mm
Motor Power	7.5kw	7.5kw	11kw	11kw	15kw
Approx weight	6600kg	7300kg	8900kg	10900kg	14500kg
Overall dimension	3300 x 1410 x 2350mm	3300 x 1460 x 2450mm	3300 x 1540 x 2460mm	3300 x 1715 x 2765mm	3300 x 1980 x 3020mm
